XAL

Floor luminaire with a rectangular luminaire head made of aluminium and rounded edges, ultra low-profile design. Pedestal with recess for table base.Direct/indirect light distribution by LGP body (Light Guiding Prism), light distribution approx. 18% direct, 82% indirect. Indirect component with special, inclined PCBs for asymmetric radiation characteristic. Completely homogeneous illumination through use of a polycarbonate based diffuser film. Workplace light suitable for VDUs according to DIN EN 12464-1 (UGR<10). with="" integrated="" infrared="" presence="" and="" brightness="">10).>Manufacturer: XALLabeling: reddot design award winnerMaterial: aluminium white powder-coated, microprismatic PMMA coverDimensions (mm): height 1930, luminaire head 800 x 320 x 15, base 490 x 320, connection cable with safety plug 3000Illuminant: 98W LED 4000KLuminous flux (Lumen): 2250 + 9960Scope of delivery: incl. illuminantDelivery time: 4 Weeks

Floor luminaire with a rectangular luminaire head made of aluminium and rounded edges, ultra low-profile design. Pedestal with recess for table base.Direct/indirect light distribution by LGP body (Light Guiding Prism), light distribution approx. 25% direct, 75% indirect. Completely homogeneous illumination through use of a polycarbonate based diffuser film. Workplace light suitable for VDUs according to DIN EN 12464-1 (UGR<13). with="" integrated="" infrared="" presence="" and="" brightness="">13).>Manufacturer: XALLabeling: reddot design award winnerMaterial: aluminium white powder-coated, microprismatic PMMA coverDimensions (mm): height 1930, luminaire head 800 x 320 x 15, base 490 x 320, connection cable with safety plug 3000Illuminant: 82W LED 4000KLuminous flux (Lumen): 2830 + 8660Scope of delivery: incl. illuminantDelivery time: 4 Weeks

Floor luminaire with a rectangular luminaire head made of aluminium and rounded edges, ultra low-profile design. Pedestal with recess for table base.Direct/indirect light distribution by LGP body (Light Guiding Prism), light distribution approx. 55% direct, 45% indirect. Completely homogeneous illumination through use of a polycarbonate based diffuser film. Workplace light suitable for VDUs according to DIN EN 12464-1 (UGR<19). with="" integrated="" infrared="" presence="" and="" brightness="">19).>Manufacturer: XALLabeling: reddot design award winnerMaterial: aluminium white powder-coated, microprismatic PMMA coverDimensions (mm): height 1930, luminaire head 800 x 320 x 15, base 490 x 320, connection cable with safety plug 3000Illuminant: 73W LED 4000KLuminous flux (Lumen): 4780 + 3890Scope of delivery: incl. illuminantDelivery time: 4 Weeks
